Deployable / E-Tool Cabinet
Model LL7D-07
 Laptop
Lockup® cabinets provide safe storage, charging and communication solutions
for deployable military maintenance technicians throughout the United States
and OCONUS.
Each technician is assigned an individually
keyed drawer to store their ruggedized computer. The drawer has the capability
to charge the laptop battery and connect the laptop to the WLAN through
a data communication connection provided by a patented coiled Cat 6 wiring
system with an Ethernet switch.
Wireless LAN solutions from Static Safe®
Products enable organizations to extend the reach of their enterprise networks
beyond offices and other wired facilities. With WLAN technology, users
in remote or hard-to-wire locations such as aircraft flight lines and
landing decks can access databases, information
and applications just as if they were connected to the wired enterprise
LAN. This E-Tool cabinet can be used as a solution for LL-7D-07 (front
view) various deployable missions and assignments.
Functions: 7 Drawer Unit:
• To easily secure 7 laptop computers,
recharge batteries and download/upload data in a deployed environment.
• Exterior case meets MIL SPEC, 810F
• No installation necessary: connect to
power supply and connect data line to switch. Cabinet is then ready to
securely
store 7 laptop computers with the capability
to recharge and/or download data while the laptop is secured in the drawer
• Patented power supply system; power
to each drawer with UL approved grounded outlet
• Patented coiled Cat 6 wiring system
with RJ45 jack connections in each drawer
• An 8 port Ethernet switch is provided
(SMC). Other switch options available, including Cisco
• Security enclosure protects Cat 6 wiring
and Ethernet switch from unauthorized access
• Locking rear door allows easy access
to internet components of cabinet
• Two fans provide positive air pressure
to keep sand and dust out and provide ventilation
• Each drawer has an independent lock,
all keyed differently, 2 master keys per cabinet
• An additional front security door provides
the user with the option to secure all 7 drawers with one locking door,
which
also provides additional protection from
sand and dust
• Drawers vented on all sides and bottom
for greater heat dissipation
• Four quick release casters are provided
and can be stored in the case
• Durable black powder coat paint (shown)
and other interior and exterior colors available)
• Lightweight, easy 4 soldier lift
• Stackable
• Filters can be washed and reused
• Life Time Warranty on the Exterior Case
and 5 Year Warranty on Interior Cabinet
Specifications: Model Number: LL7D-07
7 Drawer Unit
Exterior Dimensions: 26.5” W x 36” L x
42.5” H with casters (4.5”)
Drawer Dimensions: 15” W x 16” D x 3”
H
Approximate Weight: 235# per drawer unit
(empty) |
 |
